Sharing the same excellent properties as our A-Lite products, but with a white polyethylene core - particularly suited for applications with exposed edges.

Why use A-Lite White Core?

  • Clean, easy-peel film
  • White core, great for exposed edges
  • Digital coating - excellent for printing
  • Lightweight yet rigid
  • Uniform, flat surface
  • Two Year Guarantee for indoor and outdoor use
EXPANDCOLLAPSE
AdhesiveCo-extruded to give superior adhesionCoreWhite high quality PE core, perfect forapplications where the panel edge isvisible.Aluminium Skin0.2mm high grade aluminium providingsuperb flatness and rigidityDigital Paint FinishMultipanel's "UltraWhite" is a brightermore consistent bespoke white. Bothsides of A-Lite White Core panels havean ultra-white matt finish that hasbeen developed specifically for digitaland screen printing to help displaycolours with increased brightness andintensity with the added benefit ofgreater durability.Easy-Peel Protective FilmDesigned to protect the panel duringstorage, transit and installation,A-Lite White Core has a quality “EasyPeel” film for clean, easy removal,leaving no adhesive residue on thepanel.

Alupanel sheets have received a good feedback among our customers. The quality of the sheet is excellent.

KalusteMuovi Virtale Oy, Finland

Full Details

The A-Lite White Core aluminium composite sheet is a high quality digital print panel with a specially developed paint system, a unique 'Easy-Peel' film and the added benefit of a white polyethylene core. Particularly suited for display applications where the side of the panel will be visible, this white core helps the edge to fuse seamlessly with the face of the panel.

Offering excellent ink-adhesion, both sides of the panel have an ultra-white matt finish that has been developed specifically for digital and screen printing to help display colours with increased brightness and intensity. The high quality 'Easy-Peel' film provides excellent protection and is designed to remove smoothly and easily, leaving no residue on the panel.

For further information, you can access the product brochures and technical documents below.

VIEW BROCHURES

Applications

A-Lite White Core is suitable for a variety of flat applications particularly those where panel edges will be visible.

  • Sign Making
  • Wayfinding
  • Standoff Lettering
  • Lightweight Hanging Signs
  • POS Displays
  • Vinyl Application
  • Modular Sign Systems
  • Shop/External Fascias
  • Corporate ID
  • Exhibition Design
  • Outdoor Advertising
  • Interior Panels & Decoration
  • Direct UV & Screen Printing

Technical

Here are the sheets sizes and thicknesses available as standard, along with other technical information for A-Lite White Core.

SIZES / THICKNESSPANEL PROPERTIESDIMENSIONAL TOLERANCESSURFACE PROPERTIES
Panel Thickness (mm)3
Skin Thickness (mm)0.2
Weight (KG/m2)3.5
1000mmx2015mm
1000mmx2440mm
1000mmx2050mm
1000mmx3050mm
1220mmx2440mm
1220mmx3050mm
1250mmx2500mm
1250mmx3050mm
1500mmx3050mm
1500mmx4050mm
1525mmx3050mm
1560mmx3050mm
2000mmx3050mm
2000mmx4050mm
2050mmx3050mm
2050mmx4050mm
Panel Thickness (mm)3
Sound Absorption
Sound Attenuation
Water Absorption % by Volume
Thermal Performance R Values
Core CompositionWhite PE
Fire Performance
Tensile Strength of Aluminium Layers
Panel Thickness (mm)+/- 0.2
Width (mm)-0 +2
Length (mm)-0 +3
Diagonal-0 +5
Thermal Expansion2.4mm/m @100ºC Temp Difference
Aluminium ThicknessAs specified in EN485-4
Paint Thickness (microns)20
Pencil Hardness2H
Toughness of Coating3T
Temperature Resistance-50ºC to +80ºC
Impact Strength (kg/CM2)
Boiling Water ResistanceBoiling for 2hrs without change
Acid ResistanceSurface immersed in 2% HC1 for 24hrs without change
Alkali ResistanceSurface immersed in NaHO engine oil for 24hrs without change
Oil ResistanceSurface immersed in 20# engine oil for 24hrs without change
Solvent ResistanceCleaned 100 times with Dimethylbenzene without change
Cleaning Resistance>1000 times without change
Peel Strength>5 Newton/mm

Colours
